Electrical Motor Insulation Paper Dereeling Machine China Supplier WIND-1000G

Application:

Suitable for slitting paper,film,tape laminated film,etc.

Specification:

WIND-1000GMax. Raw material width1000mm diameter 800mm

Finished products width25-1000 mmdiameter450 mm(max)

WIND-1300GMax. Raw material width 1300mmdiameter 800mm

Finished products width25-1300 mmdiameter450 mm(max)

​
WIND-1600GMax. Raw material width 1600mmdiameter 800mm

Finished products width25-1600 mmdiameter450 mm(max)

Inside diameter of paper core 3''

Machine speed 0-120 M/min

Power Supply:220V/380V/440V 3-Phase 50/60 HZ

Techanical Data:

1. AC motor with converter works as material transfer to achieve steady and rapid progression

by acceleration and deceleration.

2. Three motors contain main motor and two rewind magnetic powder form constant control.

The main motor is for feeding and rewind, magnetic powder are for tension control so that the

finished products have stable tension and smooth appearance.

3. Rewind unit:rewind shaft uses press roller to eliminate air to make finished products

tense and nice outlook.

4. Finished product rewind:

With bar type air shaft or differential shaft,suitable for more materials.

The shaft exchange is by special design and easy to change.

5. Electricity unit:LCD touch panel is used for setting tension,length,etc.

The control system adopts Siemens PLC to control movements with detecting function

so error can be found out easily.

Please click below link to view machine video

https://youtu.be/AbpDPWfoZJw

Shanghai Wind Automation Equipment Co.,Ltd supply motor automation solution for global motor manufacturers. Setted up in the year 2010 by Senior Engineer Mr.Wang who involve in electric motor filed since 1998. Through continuous innovation and participating in globalization, it has now developed into a large enterprise that integrates R&D, production and sales to provide motor solutions for customers worldwide.

Shanghai Wind Automation built a 3C business system

1.Customized Machinery

​   Provide armature,stator motor manufacturing mchinery,

   including stand along machine, fully-auto complete production line

​

2.Characteristic Component

  Supply the full range of motor components such as commutator, magnet, fan, motor cover,etc.

3.Comprehensive Service

   Provide motor project technical support and consulting

Centered on Shanghai, the company has formed four production bases in the Yangtze River Delta city group and supplied over 20 countries including USA, Mexico,Brazil, Argentina, Turkey,France,Germany,

Czech Republic,Romania,India, Bangladesh and So on.

Our objective is to provide turn-key motor manufacturing automation equipment with no limitation

as free as the Wind, reduce the labor cost and free the human being operator,

make the life easier and more enjoyable.
